# A PDF Evolution Library

### Quick Reference

For C/C++ programs we provide in the apfel/bin folder the apfel-config script which returns the include dir and cppflags needed by g++.

apfel-config --incdir
apfel-config --cppflags
apfel-config --h

To list all functions implemented in APFEL with a short description use:

apfel-config --list-funcs

### Example

A detailed description of the functions implemented in APFEL is presented in Section 4 of the manual. An example in C/C++ is presented below, where we use the LH toy PDF set as input and then evolve at NNLO in QCD. Other examples in Fortran 77 and PYTHON are available in /apfel/examples folder.

```/**
* APFEL tutorial: How to compute the NNLO evolution using as input
* the LH toy PDF.
**/

#include "iostream"
#include 'iomanip"
#include "cmath"
#include "APFEL/APFEL.h"
using namespace std;

int main()
{
double xlha[] = {1e-7, 1e-6, 1e-5, 1e-4, 1e-3, 1e-2,
1e-1, 3e-1, 5e-1, 7e-1, 9e-1};

// Activate some options
APFEL::SetPerturbativeOrder(2);

// Initializes integrals on the grids
APFEL::InitializeAPFEL();

double Q02, Q2, eps = 1e-10;
cout << "Enter initial and final scale in GeV^2" << endl;
cin >> Q02 >> Q2;

double Q0 = sqrt(Q02) - eps;
double Q  = sqrt(Q2);
APFEL::EvolveAPFEL(Q0,Q);

cout << scientific << setprecision(5) << endl;
// Tabulate PDFs for the LHA x values
cout << "alpha_QCD(mu2F) = " << APFEL::AlphaQCD(Q) << endl;
cout << "alpha_QED(mu2F) = " << APFEL::AlphaQED(Q) << endl;
cout << endl;

cout << "   x   "
<< setw(11) << "   u-ubar    "
<< setw(11) << "   d-dbar    "
<< setw(11) << "  2(ubr+dbr) "
<< setw(11) << "   c+cbar    "
<< setw(11) << "   gluon     "
<< setw(11) << "   photon    " << endl;

cout << scientific;
for (int i = 2; i < 11; i++)
cout << setprecision(1)
<< xlha[i] << "\t" << setprecision(4)
<< setw(11) <<  APFEL::xPDF(2,xlha[i]) - APFEL::xPDF(-2,xlha[i]) << "  "
<< setw(11) <<  APFEL::xPDF(1,xlha[i]) - APFEL::xPDF(-1,xlha[i]) << "  "
<< setw(11) << 2*(APFEL::xPDF(-1,xlha[i]) + APFEL::xPDF(-2,xlha[i])) << "  "
<< setw(11) <<  APFEL::xPDF(4,xlha[i]) + APFEL::xPDF(-4,xlha[i]) << "  "
<< setw(11) <<  APFEL::xPDF(0,xlha[i]) << "  "
<< setw(11) <<  APFEL::xgamma(xlha[i]) << "  "
<< endl;

return 0;
}

```
